Max. Grinding Length : 2100mm
Max. Longitudinal Traverse : 2300mm
Width of work surface : 700mm
Max.  Grinding width with wheel engaged : 900mm
Max cross traverse : 800mm
Max. Grinding Height from magnetic check to fine wheel : 500 (700pt)
Grinding Wheel (Ø x width x bore) : 500/450 x 203 x 100mm
Table Size : 2000mm x 600mm
Table Traverse speed per minute : 	3 - 30
Cross Slide Traverse speed per minute : 	0 - 1,6
Cross feed range per stroke : 0,01 - 50
Range of automatic down feed : 0,001 - 0,07
Power of wheel motor : 20 (HP)
Approximate net weight : 13300kg
with Vertical Grinding Attachment
